Miniature Circuit Breakers
Miniature circuit breakers offer effective protection through safe disconnection in the event of an overload and short-circuit. This entire range of devices is suitable for application in houses, residential and commercial buildings as well as in industrial applications.
• Design according to IEC/EN 60898-1
• Contact position indicator red – green
• Guide for secure terminal connection
• 3-position DIN rail clip, permits removal from existing busbar system
• Comprehensive range of accessories suitable for subsequent installation
• Rated currents 1A up to 125 A
• Tripping characteristics B, C, D
• Rated breaking capacity 6 – 10 - 25 kA according to IEC/EN 60898-1
• Twin-purpose terminal (lift/open-mouthed) above and below
• Suitable for applications up to 48 V DC
• Contact position indicator red – green
• Guide for secure terminal connection
• 3-position DIN rail clip, permits removal from existing busbar system
• Comprehensive range of accessories suitable for subsequent installation
• Rated currents 1A up to 125 A
• Tripping characteristics B, C, D
• Rated breaking capacity 6 – 10 - 25 kA according to IEC/EN 60898-1
• Twin-purpose terminal (lift/open-mouthed) above and below
• Suitable for applications up to 48 V DC
